A330-800 DIMENSIONS + PERFORMANCE

Wing span
Length
Width
Height
Cabin length
Cabin width
Cabin height
Cabin Area

64m
58.5m
5.77m
17.4m
45m
5.26m
2.3m
229m

210'
193'
18' 11"
57' 1"
147' 9"
17' 3"
7' 7"
2465'

Take Off Weight
Landing Weight
Zero Fuel Weight
Empty Weight
Payload
Fuel Capacity
Fuel Burn
Range
Flight Time
Cruise Speed
Cruise Ceiling
Take-off Distance
Landing Distance

251'000kg
186'000kg
172'000kg
119'600kg
52'400kg
139'090l
7'874lp/h
19'260km
21:20hrs
903km/h
12'497m
2'220m
1'800m

553'400lb
410'060lb
388'014lb
263'672lb
115'522lb
36'750gal
1'732gp/h
10'400nm
1280min
561mp/h
41'000ft
7'280ft
5'905ft

Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

A330NEO flight deck layout

A330NEO CABIN CONFIGURATION

AIRBUS CORPORATE JET ACJ330 INTERIOR CABIN FLOORPLAN LAYOUT

A330-900 DIMENSIONS + PERFORMANCE

Wing span
Length
Width
Height
Cabin length
Cabin width
Cabin height
Cabin Area

64m
63.7m
5.77m
17.4m
50.4m
5.26m
2.3m
259sq/m

210'"
208' 10"
18' 11"
57' 1"
165' 2"
17' 3"
7' 7"
2788sq/'

Take Off Weight
Landing Weight
Zero Fuel Weight
Empty Weight
Payload
Fuel Capacity
Fuel Burn
Range
Flight Time
Crusie Speed
Cruise Ceiling
Take-off Distance
Landing Distance

251'000kg
191'000kg
181'000kg
124'500kg
56'500kg
139'090l
8228lp/h
18'334km
20:20hrs
903km/h
12'497m
2'500m
1'850m

553'400lb
421'083lb
399'037lb
274'475lb
124'562lb
36'750gal
1'810gp/h
9'900nm
1220min
561mp/h
41'000ft
8'200ft
6'070ft

Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

AIRBUS ACJ330NEO OPERATING COSTS

A330-800 VARIABLE COSTS

Maintenance
Parts (Airframe / Engine / APU)
Thrust Reverser Allowance
APU Allowance
Major Periodic Maintenance
Engine Reserves
Landing / Parking
Crew Expenses
Supplies / Catering
TOTAL COST PER HOUR

$1'000 - 2'235
$550 - 2'500
$50
$275 - 370
$2'410
$2'590 - 2'890
$435 - 605
$870 - 945
$460 - 500
$16'965 - 20'830

A330-800 FIXED COSTS

Captain (2)
First Officer (2)
Second Officer (2)
Cabin Crew (4)
Benefits
Hangar & Office Space
Hull Insurance
Liability Insurance
Modernisation
Navigation + Chart Service
Refurbishment
Computer Aided Maintenance Program
Weather Service
TOTAL COST PER YEAR

$400 - 470k
$310 - 360k
$300 - 340k
$520 - 560k
$460 - 520k
$135 - 185k
$60 - 110k
$12 - 25k
$40 - 50k
$14 - 16k
$190 - 290k
$13 - 15k
$700
$2'455 - 2'942m

Data provided for information only, actual costs specific to customer operations.

A330-800 VARIABLE COSTS

Maintenance
Parts (Airframe / Engine / APU)
Thrust Reverser Allowance
APU Allowance
Major Periodic Maintenance
Engine Reserves
Landing / Parking
Crew Expenses
Supplies / Catering
TOTAL COST PER HOUR

$1'125 - 2'515
$620 - 2'810
$60
$275 - 370
$2'665
$2'590 - 2'890
$490 - 680
$870 - 945
$520 - 560
$17'965 - 22'245

A330-900 FIXED COSTS

Captain (2)
First Officer (2)
Second Officer (2)
Cabin Crew (4)
Benefits
Hangar & Office Space
Hull Insurance
Liability Insurance
Modernisation
Navigation + Chart Service
Refurbishment
Computer Aided Maintenance Program
Weather Service
TOTAL COST PER YEAR

$400 - 470k
$310 - 360k
$300 - 340k
$520 - 560k
$460 - 520k
$135 - 185k
$60 - 110k
$12 - 25k
$40 - 50k
$14 - 16k
$190 - 290k
$13 - 15k
$700
$2'455 - 2'942m

Data provided for information only, actual costs specific to customer operations.

AIRBUS ACJ330 PRICING

interior linings

Ceilings + Sidewalls
Entry Doors + Overwing Exits
Window Shades

$3.1 - 3.7m
$120k
$1.1 - 1.4m

cabin dividers

Bulkhead
Electrical Sliding Door
Mechanical Sliding Door
Pivot Door
Curtain

$195 - 295k
$75 - 95k
$45 - 65k
$20 - 25k
$5 - 10k

cabinetry

Storage Cabinets
Desks + Tables
Beds
Galleys
Shower
Vanity
Toilet

$175 - 295k
$125 - 295k
$80 - 125k
$495 - 945k
$295 - 445k
$275 - 550k
$165 - 220k

SEATING

Track + Swivel Seat
Divan
Ottoman

$95 - 195k
$355 - 495k
$25 - 65k

special cabinetRY

Passenger Transport Unit
Armory
Ballistic Safe
Kennel
Falcon Carrier

$495 - 695k
$195 - 225k
$45 - 95k
$25 - 45k
$30 - 45k

structural modifications

Upper Attachments
Side Attachments
Floor Attachments
Wire Routing Attachments
Floorboard Modifications

$1.3 - 1.55m
$500 - 605k
$780 - 930k
$440 - 530k
$585 - 695k

interior mockups

Production Samples
Cabin Volumetric Mockup
(1/5 Cabin)
Cabin Trim + Finish Mockup
(1/5 Cabin)
Cabin Volumetric Mockup
(Full Cabin)
Cabin Trim + Finish Mockup
(Full Cabin)

‍
$15k
$125 - 160k
‍
$325 - 415k
‍
$550 - 699k
‍
$1.5 - 1.9m
‍

FINISHING MATERIALS

Woods
Leathers
Flooring
Stones
Glass + Mirrors
Metal Plating

‍
$1.2 - 1.4m
$850 - 995k
$675 - 750k
$75 - 90k
$75 - 125k
$335 - 495k

RAW MATERIALS

Composite Panel + Tooling
Consumables

‍
$1.65 - 1.95m
$630 - 750k

AIR CONDITIONING

Air-conditioning Distribution
Ventilation Distribution
Air Cleaning System
Air Heating System
Humidification System

‍
$500 - 605k
$235 - 120k
$170 - 190k
$85 - 100k
$680 - 700k

COMMUNICATIONS + connectivity

Voice + Data SATCOM System
Live TV SATCOM System
LAN + W/LAN System
Cabin Telephone System
Cabin Interphone System
Passenger Address System

‍
$995 - 1.25m
$895k - 1.15m
$240 - 345k
$180 - 225k
$30 - 45k
$45 - 65k

cabin power

Cabin Power Distribution
Utility Power System
Passenger Power System

‍
$1.4 - 1.75m
$225 - 150k
$175 - 195k

smoke detection

Smoke Detection System

$175 - 195k

indicating + recording systems

Security + Surveillance System
Anti Intrusion System
Door Warning System

$195 - 275k
$95 - 125k
$60 - 85k

cabin LIGHTING

Basic Lighting
Ambient + Accent Lighting
Decorative Lighting
Emergency Lighting System

‍
$480 - 570k
$535 - 595k
$250 - 450k
$135 - 175k

oxygen system

Chemical O2 System
Gaseous O2 System

‍
$175 - 195k
$1.5 - 1.8m

water / waste system

Water Storage + Distribution
Water Sterilization
Water Heating
Grey Water Chamber
System
Air Assisted Drain
System

‍
$565 - 665k
$120k
$360 - 540k
$520k
‍
$585 - 695k
‍

cabin management

Cabin Management System
Cabin Controllers

‍
$450 - 525k
$350 - 480k

cabin entertainment

Audio + Video Sources
Audio + Video Ports
Video Displays
Cabin Audio
Passenger Audio

‍
$160- 280k
$24k
$700 - 950k
$675 - 925k
$260k - 320k

ACOUSTIC INSULATION

52 - 56dB
Soundproofing Package
48 - 52dB
Soundproofing Package
44 - 48dB
Soundproofing Package

‍
$650 - 775k
‍
$1.25 - 1.6m
‍
$2.5 - 3.1m
‍

certification

Certification Package
Compliance Testing + Analysis

‍
$1.25 - 1.55m
$545 - 650k

testing + delivery

Ground Test Programme
Flight Test Programme
Delivery + Ferry Flights

‍
$140 - 195k
$260 - 315k
$55 - 95k

continued airworthiness

Training + Documentation
Entry into Service support
Warranty Programme
Spare Parts Provisioning

‍
$850 - 950k
$25 - 45k
$295 - 995k
$1.2 - 1.5m

project management office

Project Management
Material Handling
Travel Expenses

‍
$1.2m
$1.6m
$350k
