B787-8 DIMENSIONS + PERFORMANCE DATA

Wing span
Length
Width
Height
Cabin length
Cabin width
Cabin height
Cabin Area

60.2m
56.7m
5.77m
16.9m
42.1m
5.49m
2.4m
224.4m

197' 4"
186'
18' 11"
55' 6"
137' 11"
18'
7' 10"
2415'

Take Off Weight
Landing Weight
Zero Fuel Weight
Empty Weight
Payload
Fuel Capacity
Fuel Burn
Range
Flight Time
Cruise Speed
Cruise Ceiling
Take-off Distance
Landing Distance

227'930kg
172'365kg
161'025kg
125'736kg
35'289kg
126'206l
6'217lp/h
18'418km
20:20hrs
907km/h
13'100m
2'600m
1'520m

502'500lb
380'000lb
355'000lb
277'200lb
77'800lb
33'340gal
1'642gp/h
9'945nm
1220min
565mp/h
43'000ft
8'500ft
3'987ft

Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

b787 flight deck layout

BOEING BUSINESS JET BBJ 787 COCKPIT LAYOUT

B787 CABIN layout

BOEING BUSINESS JET BBJ 787-8 BBJ 787-9 INTERIOR CABIN FLOORPLAN LAYOUT

B787-9 DIMENSIONS + PERFORMANCE DATA

Wing span
Length
Width
Height
Cabin length
Cabin width
Cabin height
Cabin Area

60.2m
63m
5.77m
16.9m
48.2m
5.49m
2.4m
257.8m

197' 4"
206'
18' 11"
55' 6"
158' 1"
18'
7' 10"
2775'

Take Off Weight
Landing Weight
Zero Fuel Weight
Empty Weight
Payload
Fuel Capacity
Fuel Burn
Range
Flight Time
Cruise Speed
Cruise Ceiling
Take-off Distance
Landing Distance

254'012kg
192'777kg
181'437kg
133'810kg
47'627kg
126'357l
6526lp/h
17'566km
19:20hrs
907km/h
13'100m
2'800m
1'520m

560'000lb
425'000lb
400'000lb
295'000lb
105'000lb
33'380gal
1'724gp/h
9'485nm
1160min
565mp/h
43'000ft
9'300ft
3'987ft

Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

BOEING BBJ 787 OPERATING COSTS

B787-8 VARIABLE COSTS

Maintenance
Parts (Airframe / Engine / APU)
Thrust Reverser Allowance
APU Allowance
Major Periodic Maintenance
Engine Reserves
Landing / Parking
Crew Expenses
Supplies / Catering
TOTAL COST PER HOUR

$1'025 - 2'295
$565 - 2'565
$55
$280 - 380
$2'430
$2'660 - 2'970
$445 - 620
$330 - 360
$470 - 510
$16'185 - 20'110

B787-8 FIXED COSTS

Captain (2)
First Officer (2)
Second Officer (2)
Cabin Crew (4)
Benefits
Hangar & Office Space
Hull Insurance
Liability Insurance
Modernisation
Navigation + Chart Service
Refurbishment
Computer Aided Maintenance Program
Weather Service
TOTAL COST PER YEAR

$400 - 470k
$310 - 360k
$300 - 340k
$520 - 560k
$460 - 520k
$135 - 185k
$60 - 110k
$12 - 25k
$40 - 50k
$14 - 16k
$190 - 290k
$13 - 15k
$700
$2'455 - 2'942m

Data provided for information only, actual costs specific to customer operations.

B787-9 VARIABLE COSTS

Maintenance
Parts (Airframe / Engine / APU)
Thrust Reverser Allowance
APU Allowance
Major Periodic Maintenance
Engine Reserves
Landing / Parking
Crew Expenses
Supplies / Catering
TOTAL COST PER HOUR

$1'180 - 2'635
$650 - 2'945
$60
$325 - 435
$2'790
$3'050 - 3'410
$510 - 710
$330 - 360
$540 - 590
$16'495 - 22'860

B787-9 FIXED COSTS

Captain (2)
First Officer (2)
Second Officer (2)
Cabin Crew (4)
Benefits
Hangar & Office Space
Hull Insurance
Liability Insurance
Modernisation
Navigation + Chart Service
Refurbishment
Computer Aided Maintenance Program
Weather Service
TOTAL COST PER YEAR

$400 - 470k
$310 - 360k
$300 - 340k
$520 - 560k
$460 - 520k
$135 - 185k
$60 - 110k
$12 - 25k
$40 - 50k
$14 - 16k
$190 - 290k
$13 - 15k
$700
$2'455 - 2'942m

Data provided for information only, actual costs specific to customer operations.

BOEING BBJ787 PRICING

interior linings

Ceilings + Sidewalls
Entry Doors + Overwing Exits
Window Shades

$3.1 - 3.7m
$120k
$1.1 - 1.4m

cabin dividers

Bulkhead
Electrical Sliding Door
Mechanical Sliding Door
Pivot Door
Curtain

$195 - 295k
$75 - 95k
$45 - 65k
$20 - 25k
$5 - 10k

cabinetry

Storage Cabinets
Desks + Tables
Beds
Galleys
Shower
Vanity
Toilet

$175 - 295k
$125 - 295k
$80 - 125k
$495 - 945k
$295 - 445k
$275 - 550k
$165 - 220k

SEATING

Track + Swivel Seat
Divan
Ottoman

$95 - 195k
$355 - 495k
$25 - 65k

special cabinetRY

Passenger Transport Unit
Armory
Ballistic Safe
Kennel
Falcon Carrier

$495 - 695k
$195 - 225k
$45 - 95k
$25 - 45k
$30 - 45k

structural modifications

Upper Attachments
Side Attachments
Floor Attachments
Wire Routing Attachments
Floorboard Modifications

$1.3 - 1.55m
$500 - 605k
$780 - 930k
$440 - 530k
$585 - 695k

interior mockups

Production Samples
Cabin Volumetric Mockup
(1/5 Cabin)
Cabin Trim + Finish Mockup
(1/5 Cabin)
Cabin Volumetric Mockup
(Full Cabin)
Cabin Trim + Finish Mockup
(Full Cabin)

‍
$15k
$125 - 160k
‍
$325 - 415k
‍
$550 - 699k
‍
$1.5 - 1.9m
‍

FINISHING MATERIALS

Woods
Leathers
Flooring
Stones
Glass + Mirrors
Metal Plating

‍
$1.2 - 1.4m
$850 - 995k
$675 - 750k
$75 - 90k
$75 - 125k
$335 - 495k

RAW MATERIALS

Composite Panel + Tooling
Consumables

‍
$1.65 - 1.95m
$630 - 750k

AIR CONDITIONING

Air-conditioning Distribution
Ventilation Distribution
Air Cleaning System
Air Heating System
Humidification System

‍
$500 - 605k
$235 - 120k
$170 - 190k
$85 - 100k
$680 - 700k

COMMUNICATIONS + connectivity

Voice + Data SATCOM System
Live TV SATCOM System
LAN + W/LAN System
Cabin Telephone System
Cabin Interphone System
Passenger Address System

‍
$995 - 1.25m
$895k - 1.15m
$240 - 345k
$180 - 225k
$30 - 45k
$45 - 65k

cabin power

Cabin Power Distribution
Utility Power System
Passenger Power System

‍
$1.4 - 1.75m
$225 - 150k
$175 - 195k

smoke detection

Smoke Detection System

$175 - 195k

indicating + recording systems

Security + Surveillance System
Anti Intrusion System
Door Warning System

$195 - 275k
$95 - 125k
$60 - 85k

cabin LIGHTING

Basic Lighting
Ambient + Accent Lighting
Decorative Lighting
Emergency Lighting System

‍
$480 - 570k
$535 - 595k
$250 - 450k
$135 - 175k

oxygen system

Chemical O2 System
Gaseous O2 System

‍
$175 - 195k
$1.5 - 1.8m

water / waste system

Water Storage + Distribution
Water Sterilization
Water Heating
Grey Water Chamber
System
Air Assisted Drain
System

‍
$565 - 665k
$120k
$360 - 540k
$520k
‍
$585 - 695k
‍

cabin management

Cabin Management System
Cabin Controllers

‍
$450 - 525k
$350 - 480k

cabin entertainment

Audio + Video Sources
Audio + Video Ports
Video Displays
Cabin Audio
Passenger Audio

‍
$160- 280k
$24k
$700 - 950k
$675 - 925k
$260k - 320k

ACOUSTIC INSULATION

52 - 56dB
Soundproofing Package
48 - 52dB
Soundproofing Package
44 - 48dB
Soundproofing Package

‍
$650 - 775k
‍
$1.25 - 1.6m
‍
$2.5 - 3.1m
‍

certification

Certification Package
Compliance Testing + Analysis

‍
$1.25 - 1.55m
$545 - 650k

testing + delivery

Ground Test Programme
Flight Test Programme
Delivery + Ferry Flights

‍
$140 - 195k
$260 - 315k
$55 - 95k

continued airworthiness

Training + Documentation
Entry into Service support
Warranty Programme
Spare Parts Provisioning

‍
$850 - 950k
$25 - 45k
$295 - 995k
$1.2 - 1.5m

project management office

Project Management
Material Handling
Travel Expenses

‍
$1.2m
$1.6m
$350k

BOEING BBJ 787 SPECIFICATIONS
