BOEING BUSINNESS JET BBJ MAX

BBJ MAX SPECIFICATIONS

MAX 7
MAX 8
MAX 9

B737 MAX 7 DIMENSIONS + PERFORMANCE DATA

  • Wing span
  • Length
  • Width
  • Height
  • Cabin length
  • Cabin width
  • Cabin height
  • Cabin Area
  • 35.9m
  • 35.6m
  • 3.76m
  • 12.3m
  • 26m
  • 3.54m
  • 2.25m
  • 82sq/m
  • 117' 10"
  • 116' 8"
  • 13' 2"
  • 40' 4"
  • 85' 5"
  • 11' 6"
  • 7' 5"
  • 884sq/'
  • Take Off Weight
  • Landing Weight
  • Zero Fuel Weight
  • Empty Weight
  • Payload
  • Fuel Capacity
  • Fuel Burn
  • Range
  • Flight Time
  • Cruise Speed
  • Cruise Ceiling
  • Take-off Distance
  • Landing Distance
  • 80'500kg
  • 66'040kg
  • 62'900kg
  • 48'230kg
  • 14'670kg
  • 40'580l
  • 2'589lp/h
  • 12'964km
  • 15:40hrs
  • 827km/h
  • 12'496m
  • 2021m
  • 744m
  • 177'500lb
  • 145'600lb
  • 138'700lb
  • 106'328lb
  • 32'340lb
  • 10'720gal
  • 684gp/h
  • 7'000nm
  • 940min
  • 514mp/h
  • 41'000ft
  • 6'630ft
  • 2'440ft

B737 MAX 7 cargo configuration

  • Aux.
    Fuel
    Tanks
  • 9
  • 8
  • 7
  • 6
  • 5
  • 4
  • 3
  • 2
  • 1
  • 0
  • Flight
    Time
    Hours
  • 15:40
  • 15:20
  • 14:55
  • 14:30
  • 13:45
  • 13:00
  • 12:10
  • 11:30
  • 10:50
  • 10:00
  • Fuel
    Capacity
    Litres (US.Gal)
  • 40'580 (10'720)
  • 39'671 (10'480)
  • 38'743 (10'235)
  • 37'589 (9'930)
  • 35'601 (9'405)
  • 33'633 (8'885)
  • 31'646 (8'360)
  • 29'666 (7'837)
  • 27'993 (7'395)
  • 26'025 (6'875)
  • Cargo
    Capacity
    cu/m (cu/ft)
  • 8.2 (290)
  • 10.1 (357)
  • 11.3 (399)
  • 13.5 (477)
  • 15.7 (554)
  • 18.8 (664)
  • 22 (777)
  • 26.5 (936)
  • 29.4 (1038)
  • 32.3 (1140)
Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

B737 MAX 8 DIMENSIONS + PERFORMANCE DATA

  • Wing span
  • Length
  • Width
  • Height
  • Cabin length
  • Cabin width
  • Cabin height
  • Cabin Area
  • 35.9m
  • 39.5m
  • 3.76m
  • 12.3m
  • 30m
  • 3.54m
  • 2.15m
  • 106sq/m
  • 117' 10"
  • 129' 6"
  • 13' 2"
  • 40' 4"
  • 98' 5"
  • 11' 6"
  • 7' 1"
  • 1'140sq/'
  • Take Off Weight
  • Landing Weight
  • Zero Fuel Weight
  • Empty Weight
  • Payload
  • Fuel Capacity
  • Fuel Burn
  • Range
  • Flight Time
  • Cruise Speed
  • Cruise Ceiling
  • Take-off Distance
  • Landing Distance
  • 82'191kg
  • 69'309kg
  • 65.952kg
  • 49'845kg
  • 16'107kg
  • 38'743l
  • 2'607lp/h
  • 12'297km
  • 14:50hrs
  • 827km/h
  • 12'496m
  • 2020m
  • 743m
  • 181'200lb
  • 152'800lb
  • 145'400lb
  • 109'890lb
  • 35'510lb
  • 10'235gal
  • 688gp/h
  • 6'640nm
  • 890min
  • 514mp/h
  • 41'000'
  • 6'630'
  • 2'440'

B737 MAX 8 cargo configuration

  • Aux.
    Fuel
    Tanks
  • 7
  • 6
  • 5
  • 4
  • 3
  • 2
  • 1
  • 0
  • Flight
    Time
    Hours
  • 14:50
  • 14:25
  • 13:40
  • 12:55
  • 12:10
  • 11:20
  • 10:44
  • 10:00
  • Fuel
    Capacity
    Litres (US.Gal)
  • 38'743 (10'235)
  • 37'589 (9'930)
  • 35'601 (9'405)
  • 33'633 (8'885)
  • 31'646 (8'360)
  • 29'666 (7'837)
  • 27'933 (7'395)
  • 26'025 (6'875)
  • Cargo
    Capacity
    cu/m (cu/ft)
  • 22.6 (798)
  • 24.8 (875)
  • 27 (953)
  • 30.1 (1'062)
  • 33.3 (1'176)
  • 37.8 (1'335)
  • 40.7 (1'437)
  • 43.6 (1'540)
Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.

b737 max flight deck layout

boeing 737 max cockpit layout

B737 MAX CABIN LAYOUT

BOEING BUSINESS JET BBJ MAX 7 BBJ MAX 8 BBJ MAX 9 INTERIOR CABIN FLOORPLAN LAYOUT

B737 MAX 9 DIMENSIONS + PERFORMANCE DATA

  • Wing span
  • Length
  • Width
  • Height
  • Cabin length
  • Cabin width
  • Cabin height
  • Cabin Area
  • 35.9m
  • 42.1m
  • 3.76m
  • 12.3m
  • 32.6m
  • 3.54m
  • 2.15m
  • 104.1sq/m
  • 117' 10"
  • 138' 2"
  • 13' 2"
  • 40' 4"
  • 107' 2"
  • 11' 6"
  • 7' 1"
  • 1120 sq/'
  • Take Off Weight
  • Landing Weight
  • Zero Fuel Weight
  • Empty Weight
  • Payload
  • Fuel Capacity
  • Fuel Burn
  • Range
  • Flight Time
  • Cruise Speed
  • Cruise Ceiling
  • Take-off Distance
  • Landing Distance
  • 88'300kg
  • 74'344kg
  • 70'987kg
  • 53'479kg
  • 17'508kg
  • 39'671l
  • 2'719lp/h
  • 12'066km
  • 14:35hrs
  • 827km/h
  • 12'496m
  • 2499m
  • 784m
  • 194'700lb
  • 163'900lb
  • 156'500lb
  • 117'900lb
  • 38'600lb
  • 10'480gal
  • 718gp/h
  • 6'515nm
  • 875min
  • 514mp/h
  • 41'000'
  • 8'200'
  • 2'570'

B737 MAX 9 cargo configuration

  • Aux.
    Fuel
    Tanks
  • 8
  • 7
  • 6
  • 5
  • 4
  • 3
  • 2
  • 1
  • 0
  • Flight
    Time
    Hours
  • 14:35
  • 14:15
  • 13:50
  • 13:05
  • 12:20
  • 11:40
  • 10:55
  • 10:20
  • 9:35
  • Fuel
    Capacity
    Litres (US.Gal)
  • 39'671 (10'480)
  • 38'743 (10'235)
  • 37'589 (9'930)
  • 35'601 (9'405)
  • 33'631 (8'885)
  • 31'646 (8'360)
  • 29'666 (7'837)
  • 27'993 (7'395)
  • 26'025 (6'875)
  • Cargo
    Capacity
    cu/m (cu/ft)
  • 29.1 (1'027)
  • 30.3 (1'070)
  • 32.5 (1'147)
  • 34.7 (1'225)
  • 37.8 (1'335)
  • 41 (1'447)
  • 45.5 (1'606)
  • 48.4 (1'709)
  • 51.3 (1'811)
Data provided for information only, actual range and distances specific to aircraft configuration and customer operations.
BOEING BUSINESS JET BBJ MAX

BBJ MAX OPERATING COSTS

MAX 7
MAX 8
MAX 9

B737 MAX 7 VARIABLE COSTS

  • Maintenance
  • Parts (Airframe / Engine / APU)
  • Thrust Reverser Allowance
  • APU Allowance
  • Major Periodic Maintenance
  • Engine Reserves

  • Landing / Parking
  • Crew Expenses
  • Supplies / Catering

  • TOTAL COST PER HOUR
  • $380 - 850
  • $210 - 950
  • $20
  • $105 - 140
  • $900
  • $985 - 1100
  • $165 - 230
  • $330 - 360
  • $175 - 190
  • $6'395 - 7'865

B737 MAX 7 FIXED COSTS

  • Captain
  • First Officer
  • Second Officer
  • Cabin Crew (2)
  • Benefits

  • Hangar & Office Space

  • Hull Insurance
  • Liability Insurance

  • Modernisation

  • Navigation + Chart Service
  • Refurbishment
  • Computer Aided Maintenance Program
  • Weather Service

  • TOTAL COST PER YEAR
  • $200 - 235k
  • $155 - 180k
  • $150 - 170k
  • $260 - 280k
  • $145 - 165k
  • $135 - 185k
  • $60 - 110k
  • $12 - 25k
  • $40 - 50k
  • $14 - 16k
  • $190 - 290k
  • $13 - 15k
  • $700
  • $1'375 - 1'722m
Data provided for information only, actual costs specific to customer operations.

B737 MAX 8 VARIABLE COSTS

  • Maintenance
  • Parts (Airframe / Engine / APU)
  • Thrust Reverser Allowance
  • APU Allowance
  • Major Periodic Maintenance
  • Engine Reserves

  • Landing / Parking
  • Crew Expenses
  • Supplies / Catering

  • TOTAL COST PER HOUR
  • $380 - 850
  • $210 - 950
  • $20
  • $105 - 140
  • $900
  • $985 - 1100
  • $165 - 230
  • $330 - 360
  • $175 - 190
  • $6'770 - 8'240

B737 MAX 8 FIXED COSTS

  • Captain
  • First Officer
  • Second Officer
  • Cabin Crew (2)
  • Benefits

  • Hangar & Office Space

  • Hull Insurance
  • Liability Insurance

  • Modernisation

  • Navigation + Chart Service
  • Refurbishment
  • Computer Aided Maintenance Program
  • Weather Service

  • TOTAL COST PER YEAR
  • $200 - 235k
  • $155 - 180k
  • $150 - 170k
  • $260 - 280k
  • $145 - 165k
  • $135 - 185k
  • $60 - 110k
  • $12 - 25k
  • $40 - 50k
  • $14 - 16k
  • $190 - 290k
  • $13 - 15k
  • $700
  • $1'375 - 1'722m
Data provided for information only, actual costs specific to customer operations.

B737 MAX 9 VARIABLE COSTS

  • Maintenance
  • Parts (Airframe / Engine / APU)
  • Thrust Reverser Allowance
  • APU Allowance
  • Major Periodic Maintenance
  • Engine Reserves

  • Landing / Parking
  • Crew Expenses
  • Supplies / Catering

  • TOTAL COST PER HOUR
  • $380 - 850
  • $210 - 950
  • $20
  • $105 - 140
  • $900
  • $985 - 1100
  • $165 - 230
  • $330 - 360
  • $175 - 190
  • $6'995 - 8'465

B737 MAX 9 FIXED COSTS

  • Captain
  • First Officer
  • Second Officer
  • Cabin Crew
  • Benefits

  • Hangar & Office Space

  • Hull Insurance
  • Liability Insurance

  • Modernisation

  • Navigation + Chart Service
  • Refurbishment
  • Computer Aided Maintenance Program
  • Weather Service

  • TOTAL COST PER YEAR
  • $200 - 235k
  • $155 - 180k
  • $150 - 170k
  • $260 - 280k
  • $145 - 165k
  • $135 - 185k
  • $60 - 110k
  • $12 - 25k
  • $40 - 50k
  • $14 - 16k
  • $190 - 290k
  • $13 - 15k
  • $700
  • $1'375 - 1'722m
Data provided for information only, actual costs specific to customer operations.
BOEING BUSINESS JET BBJ MAX

BOEING BBJMAX PRICING

B737-MAX pricING


  • LIST PRICE
  • B737-7
  • $99M
  • B737-8
  • $121M
  • B737-9
  • $129M

B737-MAX interior GUIDE pricE


  • VVIP
  • VIP
  • GVMT.
  • EXEC.
  • AIRLINER
  • B737-7
  • $36M
  • $29M
  • $21M
  • $14M
  • $3M
  • B737-8
  • $38M
  • $31M
  • $23M
  • $15M
  • $3.25M
  • B737-9
  • $42M
  • $33M
  • $25M
  • $17M
  • $3.5M
Boeing Business Jet interior price and schedule guide
Data provided for information only, actual pricing and schedule specific to aircraft and cabin configuration.
cabin
interior
cabin
systems
project
execution

interior linings


  • Ceilings + Sidewalls
  • Entry Doors + Overwing Exits
  • Window Shades
  • $2.5 - 2.8m
  • $90 - 120k
  • $490 - 550k

cabin dividers


  • Bulkhead
  • Electrical Sliding Door
  • Mechanical Sliding Door
  • Pivot Door
  • Curtain
  • $125 - 185k
  • $75 - 95k
  • $45 - 65k
  • $20 - 25k
  • $5 - 10k

cabinetry


  • Storage Cabinets
  • Desks + Tables
  • Beds
  • Galleys
  • Shower
  • Vanity
  • Toilet
  • $175 - 295k
  • $125 - 295k
  • $80 - 125k
  • $495 - 945k
  • $295 - 445k
  • $275 - 550k
  • $165 - 220k

SEATING


  • Track + Swivel Seat
  • Divan
  • Ottoman
  • $95 - 195k
  • $355 - 495k
  • $25 - 65k

special cabinetRY


  • Passenger Transport Unit
  • Armory
  • Ballistic Safe
  • Kennel
  • Falcon Carrier
  • $495 - 695k
  • $195 - 225k
  • $45 - 95k
  • $25 - 45k
  • $30 - 45k

structural modifications


  • Upper Attachments
  • Side Attachments
  • Floor Attachments
  • Wire Routing Attachments
  • Floorboard Modifications
  • $495 - 695k
  • $195 - 245k
  • $300 - 395k
  • $175 - 220k
  • $225 - 295k

interior mockups



  • Production Samples
  • Cabin Volumetric Mockup
    (1/5 Cabin)
  • Cabin Trim + Finish Mockup
    (1/5 Cabin)
  • Cabin Volumetric Mockup
    (Full Cabin)
  • Cabin Trim + Finish Mockup
    (Full Cabin)

  • $15k
  • $125 - 160k
  • $325 - 415k
  • $550 - 699k
  • $1.5 - 1.9m

FINISHING MATERIALS



  • Woods
  • Leathers
  • Flooring
  • Stones
  • Glass + Mirrors
  • Metal Plating

  • $490 - 622k
  • $325 - 380k
  • $395 - 500k
  • $25 - 32k
  • $35 - 44k
  • $245 - 311k

RAW MATERIALS



  • Composite Panel + Tooling
  • Consumables

  • $650 - 950k
  • $245 - 360k

AIR CONDITIONING



  • Air-conditioning Distribution
  • Ventilation Distribution
  • Air Cleaning System
  • Air Heating System
  • Humidification System

  • $195 - 250k
  • $95 - 120k
  • $85 - 170k
  • $30 -45k
  • $340 - 360k

COMMUNICATIONS + connectivity



  • Voice + Data SATCOM System
  • Live TV SATCOM System
  • LAN + W/LAN System
  • Cabin Telephone System
  • Cabin Interphone System
  • Passenger Address System

  • $995 - 1.25m
  • $895k - 1.15m
  • $240 - 345k
  • $180 - 225k
  • $30 - 45k
  • $20 - 25k

cabin power



  • Cabin Power Distribution
  • Utility Power System
  • Passenger Power System

  • $550 - 750k
  • $135 - 155k
  • $150 - 175k

smoke detection


  • Smoke Detection System
  • $‍

indicating + recording systems


  • Security + Surveillance System
  • Anti Intrusion System
  • Door Warning System
  • $195 - 275k
  • $95 - 125k
  • $40 - 55k

cabin LIGHTING



  • Basic Lighting
  • Ambient + Accent Lighting
  • Decorative Lighting
  • Emergency Lighting System

  • $275 - 325k
  • $125 - 195k
  • $125 - 145k
  • $135 - 175k

oxygen system



  • Chemical O2 System
  • Gaseous O2 System

  • $75 - 95k
  • $600 - 780k

water / waste system



  • Water Storage + Distribution
  • Water Sterilization
  • Water Heaters
  • Grey Water Chamber
    System
  • Air Assisted Drain
    System

  • $215 - 280k
  • $60k
  • $270 - 320k
  • $260k
  • $225 - 295k

cabin management



  • Cabin Management System
  • Cabin Controllers

  • $265 - 295k
  • $125 - 220k

cabin entertainment



  • Audio + Video Sources
  • Audio + Video Ports
  • Video Displays
  • Cabin Audio
  • Passenger Audio

  • $160- 280k
  • $12k
  • $495 - 625k
  • $350 - 475k
  • $75k - 120k

ACOUSTIC INSULATION



  • 52 - 56dB
    Soundproofing Package
  • 48 - 52dB
    Soundproofing Package
  • 44 - 48dB
    Soundproofing Package

  • 395 - 495k
  • 745 - 945k
  • $1.1 - 1.4m

certification



  • Certification Package
  • Compliance Testing + Analysis

  • $500 - 650k
  • $210 - 295k

testing + delivery



  • Ground Test Programme
  • Flight Test Programme
  • Delivery + Ferry Flights

  • $140 - 195k
  • $280 - 350k
  • $55 - 95k

continued airworthiness



  • Training + Documentation
  • Entry into Service support
  • Warranty Programme
  • Spare Parts Provisioning

  • $350 - 450k
  • $25 - 45k
  • $295 - 995k
  • $445 - 695k

project management office



  • Project Management
  • Material Handling
  • Travel Expenses

  • $695k
  • $995k
  • $350k
BOEING BUSINESS JET BBJ MAX
